Standing Seam metal roofing s becoming more and more popular as property owners look for products that last a long time, look modern, and protect their structure.
Question: how much do you know about standing seam metal roofing? At Metal Roofing Experts, we take pride in being a leader and distributor of the metal sheet and coil products used to produce standing seam roofing systems/panels. In addition, we offer a number of engineered and non-engineered standing seam panel profile options that you can choose from. We know standing seam metal roofing.
In this article, you can expect to learn about the following:
- What standing seam metal roofing means.
- The different types and uses for standing seam panels.
- Advantages and disadvantages associated with standing seam metal roofing.
What Exactly Is Standing Seam Metal Roofing?
Standing seam metal roofing is defined as a concealed fastener metal panel system that features vertical legs and a broad, flat area between the two legs. It can also be described as having raised seams, or vertical legs, that rise above the panel’s flat area. Standing seam systems can be used for either metal roofing or metal walls.
The main idea for standing seam systems is that the fastener is hidden, whether the panel is attached to the roof deck using a clip or is directly fastened to the decking material under the vertical leg (fastener flange).
Standing Seam Panel Profile Options
One of the main selling points of standing seam metal roofing is the variety of choices and options for customers. These choices stretch far beyond just the panel’s color to include the length, width, profile, shape, thickness, etc. One of these choices is the panel profile type.
A panel profile refers to the shape and way two or more panels are seamed together. Depending on what type of roof you have, how steep it is, what environment your property is in, and various other factors, it will dictate what profile you should pick with the help of a contractor or architect. Many panel profiles comprise the standing seam category, including snap-lock, mechanical seam, batten panel, and nail/fastener flange.
Snap-Lock Profiles
Snap-lock profiles consist of panels that have been carefully roll-formed with specifically shaped edges, a male and female leg, that snap together and do not require hand or mechanical seaming during installation. Snap-lock profiles are attached to the roof deck using a clip that attaches to the seam and fastens underneath the panel. Fastener flange panels use a similar locking mechanism.
Mechanical Lock Profiles
Mechanically seamed panels are also roll-formed with specific edges that line up with each other. Once the two panels are engaged, a hand or mechanical seamer bends the edges and locks the panels together. There are two different versions of mechanical seams: Single lock 90-degree seams and double lock 180-degree seams.
Batten Panel Profiles
A batten panel roofing system is when two legs of the panels are roll-formed and then butted up next to one another. From there, a metal cap goes over the legs to create a seam, and either snaps on or mechanically seams into place. The part that goes over the legs varies quite a bit, but there are two common types: Tee seams and snap caps.
Nail Flange or Fastener Flange Profiles
Nail flange (also referred to as nail-strip) is similar to a snap-lock panel system, but instead of using a clip to attach the panel to the roof deck, it’s directly fastened down to the deck through the male leg of the metal panel. Once the fasteners are in place, the female leg of the panel snaps over the entirety of the male leg, which hides the fastener head.
Standing Seam Panel Sizing, Options, & More
In addition to different profiles to choose from, there are varying sizes that panels can be purchased at or roll-formed to on-site. The specified size is typically dictated by performance requirements, how well it works with the profile, and buyer preferences.
Panel Widths
Panel widths tend to vary by manufacturer, but most standing seam metal roof panels are between 12” and 18” in width, with approximately 16” being the most common. Unlike lap seam or other exposed fastener panels available at big box stores like Home Depot or Lowe’s, standing seam panels are not as wide as these counterparts, as doing so would impact the performance. Some rollforming machines can adjust to roll wider panels than 18”, but check with your manufacturer or installer to verify that engineering is still valid if applicable.
Seam Heights
Equally as crucial as panel widths are the heights of the standing seam portion of the panel system, which may also be referred to as the rib height. Most standing seam systems can have seams from 1” to 3”. However, 1½” and 2” tend to be some of the most common choices. For snap-lock systems, 1¾” seams are the most architecturally specified panel, especially for commercial applications.
What is in a seam has a lot to do with the panel performance. For example, the 1.5” Snap-Lock 550 performs better in uplift situations than its not-so-distant cousin, the 1.75” Snap-Lock. They look very similar, but if you look closer at the Snap-Lock 550, it not only utilizes a clip for performance, but has significant bends in the male leg of the metal for even better performance.
Striations (also called stiffening ribs or rib rollers) are the “patterns” roll-formed into a metal roofing panel between the seams. These can be used to assist with installing a metal roof, to help reduce the visibility of oil canning, or just for curb appeal. In fact, we recommend using striations in standing seam panels; some available options include:
- Flat – No indents between the seams
- Striated – Small, consistent indentation lines in the panel
- Ribbed – Shapes or indentations between the seams
- Pencil – Circular panel indents
- V-Ribs – “V” shaped panel indents
- Bead – Longer, rectangular panel indents
- Clip relief – A stiffening rib adjacent to the seam that allows the space for a clip underneath
Thicknesses
The metal coil that is roll-formed into panels comes in many different thicknesses. However, standing seam panels are typically between 22 and 26 gauges, with the most common Galvalume® (steel) thickness being 24-gauge. Aluminum standing seam panels measure between .032 and .040 inches in thickness.
Pros of Standing Seam Metal Roofing
Should Be No Exposed Fasteners
One of the most significant benefits of standing seam metal roofing is that no fasteners are visible on the surface, which means they aren’t exposed to UV, moisture, wind, and other elements that can cause a fastener to wear or fail over time. Also, standing seam systems don’t put holes in the panels that protect your structure. Some people see fastener heads as unsightly, so using a standing seam system to hide them is common. (Note: There are flashing materials that require rivets and exposed fasteners to function correctly.)
Option for Engineered Systems Tested to Perform to High Standards
Reputable manufacturers test their standing seam metal roofing systems to high industry standards, which means they are classified as engineered systems proven to perform in extreme weather. Having this engineered option is crucial in hurricane and high-wind prone areas.
Allows for Thermal Movement
When you restrict the expansion and contraction needed for proper thermal movement of a metal panel, you can run into problems, such as oil canning, fastener withdrawal, increased noise, and other issues. In standing seam metal roofing systems, the panels generally aren’t pinned, meaning they can expand and contract better. This is especially true if slider/expansion clips are installed, or, if it’s a snap-lock system, it can move freely with a clip.
Longevity & Lifecycle
Metal is already a long-lasting and low-maintenance roofing solution, especially when compared to other roofing types, such as shingles or tiles. Since the fastener doesn’t go through the metal’s surface with standing seam systems, regular maintenance to check for loosening or damaged fasteners is less frequent. However, maintaining a standing seam roof is still essential but will likely need to be performed by a professional maintenance contractor.
Warranties
More safeguards of standing seam systems are the warranties, specifically the weathertight warranties, offered by manufacturers that ensure their systems will not fail. Moreover, if it does fail, the manufacturer is responsible for making the necessary repair arrangements. Keep in mind that most weathertight warranties are only available for commercial projects.
Sleek, Consistent, & Modern Look
Standing seam is becoming more and more popular in architectural applications because of its modern and clean look. In addition to the sleek, straight lines these panel systems offer, the metal can come in virtually any color, including custom colors, to match your structure.
Architectural Freedom
Standing seam systems can be used on structures with many different planes and sophisticated, complex designs, which is why architects are specifying standing seam profiles more and more.
Energy-Efficient
Standing seam systems are frequently made with cool metal roofing coil with highly reflective pigments and emissive metal. This means these systems do an excellent job of reflecting the sun’s rays and dispelling the associated radiant heat that other roofing types may retain. In other words, cool roofing can help a building’s cooling systems work less to keep a building cool.
Different Material Options
Some consumers think that standing seam metal roofing is only available in Galvalume or other steel substrates. In fact, aluminum, zinc, and copper are all viable options for standing seam profiles. Remember to look for the engineered systems for these materials, as they will differ from the steel standards.
Mounting Options
One of the best parts about standing seam is the option to mount items, such as solar panels, snow retention systems, swamp coolers, or other rooftop addition, without ever penetrating or making any holes in the roof surface.
Disadvantages of Standing Seam Metal Roofing
Higher Cost
One of the most significant drawbacks to standing seam metal roofing is the fact that it can be more expensive when compared to other metal roofing types, especially exposed fastener systems. However, it’s not always the highest price, as metal shingles and other stamped metal materials tend to come in at a higher cost.
Less Qualified Contractors Have Experience Installing Standing Seam Roofing
Finding a contractor who is qualified, skilled, and experienced in metal roof installation is vitally important, especially because standing seam systems require careful craftsmanship. Since standing seam installations may be considered too complicated or tedious, there are far fewer contractors to choose from who have a proven track record and relevant experience.
It’s a Labor-Intensive Installation Process
For exposed fastener systems or even shingle installations, it’s a relatively simple process of putting the material on the roof deck and nailing/screwing it down. For standing seam, it’s much more complex/labor-intensive and may include:
- On-site roll-forming of the metal coil to form panels
- Appropriately spacing clips on the seam per the manufacturer’s requirements
- Fastening the clips down to the roof deck
- For snap-lock systems: Aligning the panels and snapping the legs together
- For mechanical seamed systems: Aligning the panels and hand-seaming or mechanically seaming the panel legs together
- Making any necessary slits in the metal to account for roof plans, geometry, flashings, and other items
Not to Be Used on Flat Roof Structure
Standing seam systems are not suitable for buildings or homes with a pitch below 0.5/12. These flatter pitches do not allow water to adequately drain, which could lead to premature degradation, color changes, and the overall failure of the panel system.
Can Be Harder to Repair or Replace
If damage or another issue occurs with one panel or a smaller section of the roof, it can be tough to replace efficiently because each individual panel must be separated from the ones that are staying on the structure. This process can be especially tedious for mechanically seamed systems, as each panel will need un-seamed and any sealant will need to be broken through and removed.
Other Special Precautions
Insurance and hail damage waivers – It’s important to note that many home insurance companies offer “hail damage waivers,” which lower premium prices but waives the insurance company from covering a claim for repairs or replacements caused by hail on a metal roof. Just be aware that these kinds of waivers exist and make sure to do your research or ask the manufacturer before signing.
Scratching – As is the case with any metal roof, the potential for scratching both during and after the installation is always a possibility. With standing seam metal roofing, specifically flat panels, it can be easier to see scratches. Always make sure to go outdoors often to check your roof for any signs of scratching or scuffing so you can take the appropriate measures to repair it (use a paint pen, call a contractor, or even call the manufacturer).
Final Thoughts on Standing Seam Metal Roofing
Standing seam metal roofing’s variety of options and versatility makes it an excellent choice for virtually any building type, including commercial, residential, architectural, structural, and beyond.
To wrap up, what makes standing seam metal roofing different are these four parts:
- A concealed fastener
- Two vertical legs
- A broad, flat area between the vertical legs
- A seam that stands above the flat of the panel
